Samsung
Samsung 980 Pro PCIe Gen 4.0 x4 NVMe M.2 | 500GB Storage | MZ-V8P500BW
Samsung 980 Pro PCIe Gen 4.0 x4 NVMe M.2 | 500GB Storage | MZ-V8P500BW
Couldn't load pickup availability
Maximum speed
Specifications:
Application | Client PCs |
Interface | PCIe Gen 4.0 x4, NVMe 1.3c |
Dimension (WxHxD) | 80.15 x 22.15 x 2.38 (mm) |
Weight | Max 9.0g Weight |
Sequential Read | Up to 6,900 MB/s * Performance may vary based on system hardware & configuration |
Sequential Write | Up to 5,000 MB/s * Performance may vary based on system hardware |
General Feature:
Application |
Client PCs |
Capacity |
500GB |
Form Factor |
M.2 (2280) |
Interface |
PCIe Gen 4.0 x4, NVMe 1.3c |
Dimension (WxHxD) |
80.15 x 22.15 x 2.38 (mm) |
Weight |
Max 9.0g Weight |
Storage Memory |
Samsung V-NAND 3-bit MLC |
Controller |
Samsung in-house controller |
Cache Memory |
Samsung 512MB Low Power DDR4 SDRAM |
Average Power Consumption (system level) |
Average: 5.9 W Maximum: 7.4 W (Burst mode) |
Power consumption (Idle) |
Max. 35 mW |
Allowable Voltage |
3.3 V ± 5 % Allowable voltage |
Reliability (MTBF) |
1.5 Million Hours Reliability (MTBF) |
Operating Temperature |
0 - 70 ℃ Operating Temperature |
Shock |
1,500 G & 0.5 ms (Half sine) |
Software |
Management SW |
